1. A high efficiency machine suitable for workpiece height under 1000mm.
2. Available to use various milling heads to perform multi-face or 5-face machining.
3. Suitable for high precision parts machining.
4. Suitable for precision mold machining.
5. Suitable for vehicle and aerospace parts machining.
6. Z-axis is available to fit with roller type linear ways combined with high speed spindle for high efficiency machining.
| MODEL | UNIT | UDM-2212 | UDM-2215 | UDM-3212 | UDM-3215 | |
|---|---|---|---|---|---|---|
| TABLE | Table Size | mm | 2000x1100 | 2000x1300 | 3000x1100 | 3000x1300 |
| T-Slots | mm | 22 | ||||
| Maximum Load | kg | 3500 | 4000 | 4500 | 5000 | |
| TRAVEL | X Axis | mm | 2200 | 2200 | 3200 | 3200 |
| Y Axis | mm | 1200 | 1500 | 1200 | 1500 | |
| Z Axis | mm | 760 | ||||
| SPINDLE | Spindle Servo Motor-cont./ 30min. | kW | 11/15(22/26) | |||
| Speed | rpm | 6000 | ||||
| Taper | ? | 7/24 taper NO.50, BT-50 | ||||
| DISTANCES | Between Two Columns | mm | 1300 | 1500 | 1300 | 1500 |
| Spindle Nose to Table Center | mm | 200~960 | ||||
| FEED RATE | Rapid Feed rate X/Y/Z | m/min. | 20/20/15 | |||
| Minimum Setting | mm/min. | 0.001 | ||||
| Cutting Feed rate | m/min. | 8 | ||||
| ATC | No. of Tools | pieces | 0(24/32/40) | |||
| Tool Change Time | sec. | 8(ARM TYPE) | ||||
| Max. Tool-Diameter/Length | mm | Ø125/Ø200(Without Adjacent Tool)/ Length 350 | ||||
| Max. Tool Weight | kg | 15 | ||||
| COOLANT&LUBRICATION | Coolant Tank Volume | L | 240 | |||
| Hydraulic Tank Volume | L | 70 | ||||
| Lubrication Tank Volume | L | 8 | ||||
| MISCELLANEOUS | Power Required | kVA | 40 | |||
| Pressurized Air | kg/cm² | 5~8 | ||||
| Hydraulics Required | kg/cm² | 70 | ||||
| Machine Weight | kg | 17000 | 17500 | 21000 | 21000 | |
| Controller | ? | FANUC 0iMF (32i-B/ 31i-B) (MELDAS M70/720/730) (SIEMENS / HEIDENHAIN) | ||||
